Jefferson Valve Z1314BV08AT, 24/60, 1 NPT, NEMA 4/7, 0 PSI min, 105 max, N.C., viton

Jefferson Normally Closed Solenoid Valve, Z1314BV08AT, 1 INCH NPT, 0-105 psi are ideally suited for above ground storage tanks with their Nema 4 and Nema 7 ratings, VITON seals and zero pressure differential required for operation. The Jefferson 1314 series are designed for maximum flow and ruggedness for outdoor applications for water or petroleum media. The 1314 series come with 18 inch leads on Class H, 30 watt coils as standard. The valves must be mounted up right and vertical for optimal operation.

This part number is 1 INCH, bronze body, 0-105 psi, 24/60 volts. Jefferson complete part number is Z1314BV08AT 24/60 (Old Snap Tite Part Number was Z6214BBV8A 24/60). CSA approved.

1314JV / 1342JV
