Kitagawa S2091 Large Thru Hole Open Center Hydraulic Cylinder
Regular price
$6,999.00 USD
Regular price
Sale price
$6,999.00 USD
Unit price
per
Shipping calculated at checkout.
Kitagawa S2091 Large Thru Hole Open Center Hydraulic Cylinder
- Standard thru hole type
- Compact and light weight
- Built-in check valve and relief valve
| Brand | Kitagawa |
| Type | Hydraulic Cylinder |
| Style | Open Center |
| Model Number | S2091 |
| Piston Diameter (mm) | 205 |
| Piston Stroke (mm) | 30 |
| Piston Area Push Side (cm²) | 252 |
| Piston Area Pull Side (cm²) | 234 |
| Draw Bar Push Side (kN[kgf]) | 94.0 [9585] |
| Draw Bar Pull Side (kN[kgf]) | 88.0 [8973] |
| Max Operation Pressure (MPa[kgf/cm²]) | 4.00 [40.8] |
| Max RPM | 3800 |
| Country of Origin | Japan |
