Edgecore Networks EPS122 (AS4625-54P) | 1G Campus Switch

ATA SHEET

Nile NSW 200 48-port Gigabit Access Switch

NSW 200 Differentiators

•

•

•

•

•

•

Ports secured with zero trust, requiring authentication and authorization before IP address

assignment to connected devices.

Elimination of Layer 2 VLANs for enhanced security

No lateral movement prevents malware intrusions with zero trust isolation of each connected

device at Layer 3 (L3)

Mutual authentication between switches ensures strict confirmation and authenticity, protecting

against MITM attacks

No local/console port to prevent unauthorized access

Dynamic device fingerprinting and SSO, 802.1X, MAB authentication flows supported on each wired

port

CAPABILITIES

Connectivity and POE

•

•

•

•

•

48x Gigabit (10M/100M/1000M) and 6x 10G built-in uplinks ports.

Copper interfaces for downlink/client ports

Copper and Fiber support for Uplink ports

Support for Energy-Efficient Ethernet (EEE)

IEEE 802.3at and 802.3bt Power over Ethernet (PoE) type 4 up to 90W

Power Supplies, Fans, Mounting, LEDs

•

•

•

•

•

•

•

Dual Redundant Load sharing power supplies, Hot Swap support, Easy access for Field Replacement

Power Supply LEDs: Output Fail - RED, Input OK - GREEN

GE RJ-45 SFP+ Port LEDs: Link Status, Activity

SFP+ Port LEDs: Port LEDs: Link Speed, Link Status, Activity

Ethernet Management Port LED: Link Status, Activity

System LEDs: System, PSU1, PSU2, FAN, PoE, LOC

Fixed 2+1 redundant fans

•

Front-to-back airflow

•

Rack Mounting” 2-post and 4-Post support - kits provided

Power Budget

•

•

Total Power: 850W, 1PSU (Including PoE)

Total Power: 1850W, 2PSU (Including PoE)

Security

•

•

Support TPM 2.0 with SPI Interface

UEFI Secure Boot capability for CPUDATA SHEET

Nile NSW 200 48-PORT Gigabit Access Switch

SPECIFICATIONS

I/O ports and slots

48 10M/100M/1000M RJ-45 ports

6 1G/10G SFP+ ports

Additional ports and slots

Micro-USB for Bluetooth Interface

Physical Characteristics

Dimensions 1 RU H x 17.32” W x 13.79” D (44mm x 440mm x 350mm)

Weight 18.6 LBS (8.44 Kg)

Environment

Operating temperature 0°C to 45°C

Operating Humidity 5% to 90% Relative Humidity, non-condensing

Max non-operating/storage

specification

Storage temperature: -40°C to 70°C

Storage Humidity: 5% to 90% RH, non-condensing

MTBF 405,313 hrs at 77°F (25°C)

Electrical

Power Input Low-line: 90-136VAC; High-line: 180-264VAC

Power Cable ARG Argentina 220V AC 10A 2-meter AC Power Cord JW113A

AUS Australian AC Power Cord JW114A

BR Brazil AC Power Cord JW115A

CHN China AC Power Cord JW116A

DEN Denmark 220V AC 10A 2-meter AC Power Cord JW117A

IN India AC Power Cord JW119A

IL Israel 250V AC 10A 2-meter AC Power Cord JW120A

IT Italian AC Power Cord JW121A

JP Japanese AC Power Cord JW122A

KOR Korea AC Power Cord JW123A

NA North America AC Power Cord JW124A

EC Continental European/Schuko AC Power Cord JW118A

Compliance

FCC, CE, IC, CSA EMC, Immunity, Safety, Radio directive, ROHS5

Certifications

Available with US Trade Agreements Act (TAA) compliance;

USGv6 Host and Router Certified;

Bystander positions operating to an ambient temperature of 25°
